STRUCTURAL DETAILING
Structural detailing breaks down and translates the engineers structural design into the fabricated components showing all fixings, footings and weldments. This information is then used for the fabrication of all of the components and erection/install.
With this service I offer a range of programs to suit a companies existing software and system database, including Solidworks, Inventor, Advanced Steel and Fusion 360.
Utilising Building Information Modeling (BIM) , I am able to create a virtual 3D environment of the structure, allowing me to identify and resolve any potential conflicts for all fabricated & non-fabricated components such as fasteners, tension rods, and more.
This service will include the delivery of a complete structural drawing set with quantities for all structural elements.
If this process is completed in shop and the service you require is for fabrication/workshop drawings only please see the Workshop Drawings page for more information
Disclaimer: Engineering services are not provided.
